Product Details
The range of air differential pressure transmitters is designed for ventilation, fan speed control, air pressure monitoring, and control system applications.
The key features of this Modbus Pressure Sensor include:
- 24 Vdc Supply
- -250 to +2500 Pa Range
- Temperature Compensated (0°C to 50°C)
- Network Communicated Output (Modbus RTU RS485) with LED display
- Digital Self Damping
- Solid state temperature compression pressure cell with microprocessor providing superior linearity, measurement accuracy and sensitivity
- Supplied fully calibrated
- Zero pressure setting at the touch of a button
- The standard sensor housing is rated at IP65
- The Modbus Pressure Sensor is supplied with two metres of tube and two duct pilot fittings
